描述：IRAMX16UP60A-2 is an iMOTION series integrated power module developed and optimized for electronic motor control in appliance applications and variable speed compressor drives. Plug N Drive technology offers an extremely compact, high performance AC motor driver in a single isolated package for a very simple design. An open emitter configuration of the low side IGBT switches offer easy current feedback and over current monitor for high precision and reliable control. A built in temperature monitor and over current protection, along with the short circuit rated IGBTs and integrated under voltage lockout function, deliver high level of protection and fail safe operation. The integration of the bootstrap diodes for the high side driver section, and the single polarity power supply required to drive the internal circuitry, simplify the utilization of the module and deliver further cost reduction advantages. . Integrated gate drivers and bootstrap diodes . Temperature and over current shutdown . Under voltage lockout for all channels . Matched propagation delay for all channels . Low side IGBT emitter pins for current control . Schmitt triggered input logic . Cross conduction prevention logic . Lower di/dt gate driver for better noise immunity . Motor Power range 0.75KW to 2KW/85Vac to 253Vac . Isolation 2000VRMS/min
