描述：DESCRIPTION: The FCT16374T/AT/CT/ET and FCT162374T/AT/CT/ET 16-bit edge-triggered D-type registers are built using advanced dual metal CMOS technology. These high-speed, low-power registers are ideal for use as buffer registers for data synchronization and storage. The Output Enable (xOE) and clock (xCLK) controls are organized to operate each device as two 8-bit registers or one 16-bit register with common clock. Flow-through organization of signal pins simplifies layout. All inputs are designed with hysteresis for improved noise margin. The FCT16374T/AT/CT/ET are ideally suited for driving high-capacitance loads and low-impedance backplanes. The output buffers are designed with power off disable capability to allow "live insertion" of boards when used as backplane drivers. The FCT162374T/AT/CT/ET have balanced output drive with current limiting resistors. This offers low ground bounce, minimal undershoot, and controlled output fall times– reducing the need for external series terminating resistors. The FCT162374T/AT/CT/ET are plug-in replacements for the FCT16374T/AT/CT/ET and ABT16374 for on-board bus interface applications. FEATURES: ? Common features: ?? – 0.5 MICRON CMOS Technology ?? – High-speed, low-power CMOS replacement for ABT functions ?? – Typical tSK(o) (Output Skew) < 250ps ?? – Low input and output leakage ≤1μA (max.) ?? – ESD > 2000V per MIL-STD-883, Method 3015; ????? > 200V using machine model (C = 200pF, R = 0) ?? – Packages include 25 mil pitch SSOP, 19.6 mil pitch TSSOP, 15.7 mil pitch TVSOP and 25 mil pitch Cerpack ?? – Extended commercial range of -40°C to +85°C ?? – VCC = 5V ±10% ? Features for FCT16374T/AT/CT/ET: ?? – High drive outputs (-32mA IOH, 64mA IOL) ?? – Power off disable outputs permit “l(fā)ive insertion” ?? – Typical VOLP (Output Ground Bounce) < 1.0V at VCC = 5V, TA = 25°C ? Features for FCT162374T/AT/CT/ET: ?? – Balanced Output Drivers: ±24mA (commercial), ±16mA (military) ?? – Reduced system switching noise ?? – Typical VOLP (Output Ground Bounce) < 0.6V at VCC = 5V,TA = 25°C
